DZJ series air-cooled Roots vacuum pump is based on the ordinary Roots vacuum pump to add a bypass gas cooling system. The external cooler automatically circulates the gas to cool the rotor and the pump body, and the cooling gas enters the suction chamber of the pump from both sides of the pump body, so that the pump will not overheat due to the compressed gas, so that it can operate reliably under the high pressure difference and high compression ratio for a long time, but has no effect on the pumping performance of the pump. The pump can be used alone or in series, or in series with liquid ring vacuum pump and ordinary Roots vacuum pump to achieve a higher vacuum degree to meet various process requirements.

Product characteristics

● Can be directly discharged into the atmosphere, no waste water discharge;

● Can be connected with the front pump in series to form Roots unit, energy saving effect is remarkable. Compared with ordinary Roots pump, because ZJQ air-cooled Roots vacuum pump can work under high pressure difference, the front pump can be appropriately reduced to achieve energy saving effect.

● Wide application range. Because the exhaust side can withstand high pressure, it effectively solves the phenomenon of overload and overheating caused by excessive pressure difference and poor vacuum degree of the common Roots vacuum pump;

● Can work under higher inlet pressure. ZJQ series air-cooled Roots vacuum pump can theoretically work under the condition of atmospheric pressure at the inlet;

● The motor power is uncertain. ZJQ series air-cooled Roots vacuum pumps need to calculate the maximum pressure difference during actual operation according to the process conditions to determine the required motor power.

技术参数

应用领域

气冷罗茨真空泵广泛应用于各种工业领域，如半导体制造、真空冶金、真空干燥、真空包装等。具体来说，气冷罗茨真空泵可以用于以下几个方面：

半导体制造：气冷罗茨真空泵可以用于半导体制造过程中的真空抽气，如薄膜沉积、离子注入等。

真空治金：气冷罗茨真空泵可以用于真空治金过程中的真空抽气，如真空熔炼、真空淬火等。

真空干燥：气冷罗茨真空泵可以用于真空干燥过程中的真空抽气，如食品干燥、木材干燥等。

真空包装：气冷罗茨真空泵可以用于真空包装过程中的真空抽气，如食品包装、药品包装等。

☆ 在线精密计量添加                                                           ☆ 双组份在线计量

☆ 狭缝涂布计量输送                                                           ☆ 高粘流体计量输送

☆ 涂胶                                                                               ☆ 喷涂

☆ OCA涂覆                                                                       ☆ 聚酰亚胺薄膜

☆ 光学膜                                                                           ☆ 屏幕保护膜

☆ 窗轨润滑注入                                                                 ☆ 窗膜
