RPP series water jet vacuum pump is a mechanical device with three effective functions, such as vacuum pumping, condensation and drainage. RPP water jet vacuum pump using reinforced polypropylene plastic molding, the pump can pump temperature within 150℃ corrosive gas, and steam jet pump in series use, higher vacuum. Compared with the same type of products, the service life is longer, the exhaust volume is larger, the vacuum is higher.
Product characteristics
1. The nozzle adopts a multi-nozzle structure to obtain a larger water-steam contact area, which is conducive to heat exchange and better vacuum effect.
2. Nozzle base machining precision, high precision, so that the jet water accurately gathered in the same focus.
3. The guide plate is used to slow down the flow rate of steam (or air), so that the steam is uniformly imported into the chamber to avoid the skew of the jet water and reduce the efficiency of the injection.
RPP水喷射真空泵 | |||||
型号 | 极限真空度 | 保证真空度 | 最大抽气量 m3/h | 配套泵型号及功率 | |
-Mpa | kW | ||||
-Mpa | mmHg | ||||
RPP-25-20 | 0.0985 | 0.098 | 735 | 20 | 40F(D)-18(1.5) |
RPP-32-40 | 0.0985 | 0.098 | 735 | 40 | 50F(D)-22(2.2) |
RPP-40-60 | 0.098 | 0.097 | 728 | 60 | 50F(D)-25(3) |
RPP-54-90 | 0.098 | 0.097 | 728 | 90 | 65F(D)-28(4) |
RPP-54-110 | 0.0985 | 0.0975 | 732 | 110 | 80F(D)-30(5.5) |
RPP-54-180 | 0.0993 | 0.098 | 735 | 180 | 80F(D)-30(5.5) |
RPP-54-220 | 0.0996 | 0.0984 | 738 | 220 | 100F(D)-32(15) |
RPP-65-280 | 0.0993 | 0.098 | 735 | 280 | 80F(D)-32(7.5) |
RPP-65-360 | 0.0995 | 0.098 | 735 | 360 | 100F(D)-32(11-25) |
RPP-80-500 | 0.0995 | 0.098 | 748 | 500 | 100F(D)-32(15) |
蒸汽喷射泵 | 0.1 | 0.0996 | 748 | 汽水串联与180、280、360、500配套，耗气量40kg/h，工作气压0.3Mpa | |
注： | |||||
①实际真空度是根据当地当时的大气压×本技术参数的真空度。 | |||||
②表内性能为气体温度20℃，大气压力为101.325KPa（相当于760mmHg），气体相对湿度70%，水循环供水温度15℃时的性能。 | |||||
③抽气速率容差±10%。 | |||||
④表内真空度数值，是指负于标准大气压的那部分压力。 | |||||
（1mmHg=1Torr=133.3Pa，0.1MPa=750mmHg） | |||||
应用领域
广泛应用于化工、制药、纺织、食品、酿造、冶金、环保等行业，主要应用真空吸收、真空过滤、真空浓缩、真空干燥、真空输送、真空除氧、真空增氧等工艺。
